What is a permit site plan?
A site plan is a scaled drawing of your property from above. It shows what exists today and where the new work will go. Permit reviewers use it to check dimensions, setbacks, access and coverage before they approve the project.
A site plan is not the same as
- A legal boundary survey
- An engineering drainage design
- A construction plan set
These can be separate requirements. We tell you which ones your project needs before you pay for anything.
What your site plan can include.
Every plan is project-specific. These are the items permit offices ask for most often.
- Property lines, bearings, dimensions and lot area
- North arrow, scale, street names and address
- Existing house, buildings, sheds, patios and hardscape
- Proposed work with length, width and placement
- Front, side and rear setbacks where verified
- Distance between buildings and access details
- Driveway, parking and walkway information
- Recorded easements from available documents
- Existing and proposed building and impervious coverage
- Utility, septic, drainage or flood references when in scope
- Legend, notes, date and organized title block
- City-review revisions within the agreed scope
A boundary, topographic or elevation certification cannot come from approximate GIS data. For coverage rules, see how lot coverage is calculated.
